Body Temperature Monitor Manufacturer - China

body temperature monitor manufacturer Sensor probe: imported thermal infrared imaging probe, compared with ordinary infrared receiver on the market, has the advantages of high sensitivity, high pixel, high resolution, area array imaging, etc;

High passing rate: normal slow walking through, face side view indicator light, passing rate ≈ 40-60 people / min;

Avoid missing inspection: the product design conforms to the ergonomics, which can ensure that the subject cannot avoid the probe and the inspection

Detection accuracy: the detection result can be accurate to two decimal places.

Under normal room temperature, the temperature error is ± 0.5 ℃; under the stop and stay mode, the temperature error is no more than ± 0.3 ℃;

Irradiation angle: large area conical fan type;

System function: the number of green light prompt, high temperature alarm red light prompt, number of records;

Audible and visual alarm: when the temperature of the tested person is abnormal through the temperature measuring door, the red signal light flashes, and gives a sound prompt to the detection personnel, and the number of alarms can be stored;

Intelligent statistics: intelligent passenger flow and alarm counting function, which can automatically count the number of people passing and the number of alarms

Very low power consumption: normal working power 1000W;

Detection height: the probe can move up and down, adapt to different height, different age groups;

Parameter setting: the main parameters such as sensitivity, accuracy, temperature can be debugged according to the customer's use scenario;

Working mode: 1 - normal passing mode; 2 - slow side mode; 3 - stop stop mode;

Positioning system: tracking personnel's real-time position through ultrasonic microwave

Detection distance: < 50cm

Optional module: blackbody automatic calibration module

We are body temperature monitor manufacturer.

Working humidity 95%, non condensing

Temperature measurement range 25 ℃ ~ 48 ℃

Temperature measurement error ± 0.5 ℃ (at room temperature)

± 0.3 ℃ (constant room temperature) in specific mode

Working voltage wide voltage ac180-250v, 50-60Hz

Working frequency automatic or manual adjustment according to the installation environment

Power 1000W

Net weight 50kg

Channel size 1950mm (H) × 700mm (W) × 500mm (d)

Boundary dimension 2150mm (H) × 780mm (W) × 500mm (d) (if there is any change to the boundary, it will not be notified, the actual object shall prevail)
