Black 2 5mm Single Core Xlpe High Quality Solar Pv Cable - China

Widely used in indoor and outdoor solar installations, electrical installation, indoor and outdoor, explosion-prone areas, factories, industrial and agricultural industries.

Low smoke without halogen, good cold, ultraviolet, ozone - resistant and weather - resistant.

Flame retardant, cutting resistance and penetration resistance.

Cable protection level Ⅱ level.

With 150 ℃ photovoltaic cable radiation as insulation materials, halogen free flame retardant is halogen-free, non-toxic modified polyethylene thin hengjing resin as the main raw material, add halogen-free, non-toxic, flame retardant, heat stabilizer, eliminate smoke agent, preservative, such as fertilizer, does not contain halogen, heavy metals, phosphorus.

It conforms to ROHS, and the insulation resistance is small after immersion.

1 - The dc resistance: the finished cable at 20 ℃ conductive wire core dc resistance is not greater than 5.09 Ω/km 2 - The insulation resistance: the finished insulation resistance of cable at 20 ℃ should not less than 1014 Ω.

Cm, finished cable insulation resistance at 90 ℃ is not less than 1011 Ω.

Cm

Ambient temperature: - 40 ℃ ~ + 90 ℃

The highest temperature of conductor: 120 ℃ (allow 5 s in short circuit temperature 200 ℃)

Limited voltage: AC0.6/1kv dc1.8kv 3 - The sheath surface resistance: resistance of the finished cable sheath surface should be not less than 109 Ω.
