Lattice Structure Transmission Tower - China

price: contact company for price

Lattice Structure Transmission Tower

Products Photos Catalog Lattice Structure Photos Catalog

A lattice structure transmission tower is a type of electricity pylon that is widely used for high-voltage power transmission.

As the name suggests, these towers are characterized by their lattice-like steel frameworks, which provide the necessary strength to support overhead power lines while minimizing the amount of material used.

Product lattice structure transmission tower

Shape lattice

Material Normally Q345B/A572, Minimum Yield Strength ≥ 345 N/mm² Q235B/A36, Minimum Yield Strength ≥ 235 N/mm².

OR Q420 Q460 ASTM A572 GR65, GR50, SS400

Electric Voltage 10kv, 11kv, 32kv, 33kv, 35kv, 65kv, 66kv, 90kv, 92kv, 110kv, 115kv, 132kv, 220kv, 230kv, 300kv, 320kv, 330kv, 345kv, 380kv, 400kv 500kv, 750kv, 765kv, 800kv, 850kv, 1000kv, 1100kv

Surface treatment Hot dip galvanized Following ASTM A 123, BS729 or as client required.

connection bolt connection

Standard ISO 9001: 2008

Height: below 60 meters

Surface treatment: galvanization and color painted

Welding Standard AWS (American Welding Society ) D 1.1

Production Process Raw material test → Cutting →Welding →Hole drilling →Dimension verify →sample assemble → surface clean→ Galvanization or powder coating, painting →Recalibration →Packages

Packages Packing with plastic paper, steel box or according to client’s request.

Deshi Tower specializes in the design, manufacture, and construction support of transmission towers, communication towers, steel structures, and observation towers.

Transmission tower design adheres to ASCE/SEI standards.

Telecommunication tower design follows ANSI/TIA-222 standards.

We are not just manufacturers and suppliers, but also your technical support and partners.


Company Contact:


  • Phone: +865368666318

  • Address: No.322 YinfengRoad, weifang , china , China

  • Email: Email


Published date: June 17, 2024

  • Business Description: Design, Manufacturing, and Construction Support for Transmission Towers, Telecom Towers, Steel Structure Buildings, Weather tower, Observation Towers, Microwave Towers, and Lightning Towers.
