SMT PCB Gate Conveyor

SMT PCB Gate Conveyor Description

SMT PCB Gate Conveyors are conveyor systems that are used to transport PCBs (printed circuit boards) through different stages of the manufacturing process.

They are commonly used in the production of electronic devices and are designed to move PCBs efficiently and accurately from one station to the next.

SMT PCB gate conveyors can be used to automate the process of moving PCBs through different stages of production, such as assembly, inspection, and testing, and can also be used to transport PCBs between different stations or processes in a manufacturing facility.

These conveyors can be equipped with vision systems or other inspection systems to help ensure that PCBs are being moved accurately and efficiently, and can help to reduce the risk of damage to PCBs during transport.

Hayawin's Gate Conveyor, Custom SMT PCB Gate Conveyor is fully equipped to provide excellent stability and performance to handle printed circuit boards in SMT manufacturing.

You can contact us for more customization details.

Hayawin Gate Conveyor Features

● Panasonic PLC controller.

● Fully covered design, 4 sensors detection channel pass, high security

● Normal opened for conveying, closed when require a passageway which width is600mm

● Cylinder driven for smooth extension and retraction.

● Smooth and parallel rail width adjustment.

(T-type screw)

● SMEMA compatible.

Custom SMT PCB Gate Conveyor Specifications

Dimension: L1200 (opened) mm*W890mm*H1200mm

Max PCB size: L500*W460mm

Transport height: 920±20mm

Transfer direction: Left to right/right to left

Interface: SMEMA

Power supply: 100-230V AC

Power voltage: 50w

Air supply: 4-6bar

Air consumption: Max 10L/min

Telescopic stroke: 600mm

Cycle time: ±20s

Applications of SMT PCB Gate Conveyor

Automating the PCB manufacturing process: SMT PCB gate conveyors can be used to automate the process of moving PCBs through different stages of production, such as assembly, inspection, and testing.

This can help to increase efficiency and reduce the risk of errors.

Transporting PCBs between different stages of production: SMT PCB gate conveyors can be used to transport PCBs between different stations or processes in a manufacturing facility, such as from an SMT pick and place machine to a reflow oven.

Quality control: SMT PCB gate conveyors can be equipped with vision systems or other inspection systems to help ensure that PCBs are being moved accurately and efficiently, which can be important in maintaining quality control standards.

Reducing the risk of damage: SMT PCB gate conveyors can help to reduce the risk of damage to PCBs during transport, which can save time and reduce the costs associated with rework and repair.

About Hayawin

As a professional SMT equipment manufacturer with a wide range of business including development, design, development, manufacturing and sales of whole factory automation equipment, Hayawin insists on providing customers with the right products, reasonable prices and excellent service to ensure high-quality and long-life of products.

Our main products include the board handling equipment of SMT, automatic labeling machine, automatic board loader and unloader, High-speed vacuum loader, PCB turning machine, conveyors, etc.

We also provide a one-stop customized service to meet the different needs of different industries.
