Anti Corrosion Powder Coating For Drinking Water Pipes - China

Product Introduction:

This product is formulated using special epoxy resins, dedicated curing agents, and food-grade pigments and fillers.

It features high reactivity, strong adhesion, high cross-link density, and excellent resistance to chemicals, solvents, cathodic disbondment, as well as superior flexibility and impact resistance.

Product Features:

Excellent adhesion to the substrate.

Good leveling and high gloss on the coating surface.

Strong resistance to permeation and corrosion.

High surface hardness and dense coating.

Superior high-temperature cathodic disbondment resistance.

Low melting temperature, high reactivity, and high curing completion rate.

Good mechanical properties and extremely strong flexibility.

Complies with safety evaluation standards for materials in contact with drinking water.

Powder Coating Performance Parameters：

Item Quality Indicator Test Method

Appearance Uniform color, no lumps Visual inspection

Color As per customer requirements —————

Density (g/cm³) 1.3-1.5 GB/T 4472

Non-Volatile Content (%) ≥ 99.4 GB/T 6554-1986

Magnetic Substance Content (%) ≤ 0.002 GB/T 2482-1986

Cured Powder Coating Performance Parameters：

Test Item Technical Indicator Test Method

Appearance Smooth, uniform color, no bubbles, cracks, or pinholes; slight orange peel allowed Visual inspection

Adhesion (Grade) 1-3 SY/T 0442-1997

Cathodic Disbondment Resistance (65°C, 48h) (mm) ≤ 8 SY/T 0413-95

Flexibility (40) No cracks SY/T 0442-1997

Electrical Strength (MV/m) ≥ 30 GB/T 1408-1989

Impact Resistance ≥ 11 SY/T 0442-1997

Chemical Resistance Qualified GB/T 1763-1979

Abrasion Resistance (1000g, 1000 cycles) ≤ 20g GB/T 1768-1979

Salt Spray Test (1000h) No change in coating GB/T 1771-1991

Flattening Test (Flattening ratio 4/5) No cracks at welds CJ/T 120-2008

Water Quality Soaking Test Qualified GB/T 17219-1998

Compliance Standards:

CJ/T 120-2008 - GB/T 17219-1998 Application Fields:

Municipal drinking water supply pipes.

Application Processes:

Electrostatic spraying, dip coating, etc.

Precautions:

The steel pipe surface should be free of oil and moisture; the surface treatment quality should reach Sa2 1/2 level (GB/T 8923); the anchor pattern depth should be 50-90 mm; dust and abrasives on the steel pipe surface should be blown clean.

Preheating temperature should be controlled between 180-230°C.

The product should be stored in a well-ventilated, dry indoor environment with a temperature below 30°C, away from heat sources, corrosive chemicals, and chemical solvents, and protected from strong light exposure.

The stacking height should not exceed four layers.

Avoid long-term pressure and ensure the packaging box is sealed to prevent caking and moisture, which can affect fluidization performance.

To ensure thorough curing of the epoxy coating and better anti-corrosion performance, it is recommended to preheat the steel pipe surface to above 170°C to improve the curing completion rate.

Do not mix with other anti-corrosion powders or recycled powders.

Thoroughly clean the spraying equipment when changing colors to ensure drinking water safety and compliance with health standards.
