Architectural Aluminium Powder Coating Mt D1036 Gloss Satin Matt - China

Product Description

MT-D1036 Gloss/ Satin/ Matt is a range of durable powder coatings specially formulated without of TGIC for use on architectural aluminium components.

MT-D1036 Gloss/ Satin/ Matt typically meets the performance requirement of AAMA 2603, AS 3715 and Qualicoat 1 specifications.

MT-D1036 Gloss/ Satin/ Matt is designed to provide excellent exterior durability and colour retention and conforms to the requirements of all the major Asia architectural finishing standards.

All MT-D1036 powders are lead-free available in a wide range of color in full gloss such as high gloss, satin and matt finishes.

It is designed to produce texture, pearlescent and other special effects can be custom matched to the users’ requirements.

Powder Properties

Chemical Type Polyester

Gloss level (60°) Depend on the colour

Specific Gravity 1.2-1.75 g/cm³ depending on colour and effect

Particle Size Suitable for electrostatic spray

Storage Dry cool conditions below 30°C (open boxes must be resealed)

Shelf life 12 months below 30°C

Curing schedule

(at object temperature) 10 minutes at 200°C

Mechanical Tests

Flexibility ISO 1519 (cylindrical Mandrel) or ASTM D522 Pass 5mm

Adhesion ISO 2409 / ASTM D 3359 (2mm crosshatch) Gt0

Erichsen cupping ISO 1520 Pass >3mm

Impact resistance ISO 6272: 1993 / ASTM D2794 Pass 2.5 Joules (reverse & direct (20 in lb)

Pre-treatment

For maximum protection it is essential to pretreat components prior to the application of MT- D1036 Gloss/ Satin/ Matt Aluminium components should receive a full multi-stage chromate conversion coating or suitable chrome-free pre-treatment or suitable pre-anodising to clean and condition the substrate.

Detailed advice should be sought from the pre-treatment supplier.

Galvanised steel requires surface preparation by either multi-stage pretreatment using either zinc phosphate or chromate conversion or controlled sweep blasting.

Depending on the type of galvanizing, degassing or use of anti-bubbling additives may be required – follow the procedural advice of the pretreatment supplier.

MT-D1036 products may also be used on cast or mild steel.

For outdoor use, MT-PZ anti-corrosive primer over a correctly prepared substrate is recommended.

Application

MT-D1036 Gloss (85) powders can be applied by manual or automatic electrostatic spray or tribo-charging equipment.

For solid shades, unused powder can be reclaimed up to a maximum of 30% using suitable equipment and recycled through the system.

MT-D1036 powders should be applied at minimum 60µm.

All powders can show small colour differences from batch to batch, this is normal and unavoidable.

Applicators and fabricators are advised to use a single batch for parts that will be assembled together.

Differences are more likely with special effect powders.

Bonded products have better application properties than blended products (more stable) but attention should still be paid to line settings in order to avoid “marble effect”and changes in aspect after recycling.

A constant ratio between virgin and recycled powders should be fixed by the coater in order to achieve a consistent effect.

For more details it is suggested to read the “Metallic Application Guideline”.

Different substrates (aluminium, steel, galvanized steel…), use of primer, and big changes in film thickness may give a different aspect.

Products with different codes should not be mixed even if same colour and gloss.
