Promotional Dip Outdoor Full Color Led Module - China

Overview

Specifications

Place of Origin:

Shanghai, China (Mainland)

Brand Name:

Ledlord

Model Number:

outdoor DIP P12

Usage:

Outdoor

Tube Chip Color:

Full Color

Display Function:

video, image, text, message and so on

Pixels:

12mm

Screen Dimension:

Customized Size

Name:

dip outdoor full color led module

Other name:

outdoor led display

Certificate:

CE ROHS FCC ISO

Pixel pitch:

PH12

Color:

Full-color

LED chip:

Epistar

Module size:

192*192mm

Warranty:

2 Years

Life span:

100000hours

Application:

Square, Adervertising, Bank, Hall, Rent and soon

Packaging & Delivery

Packaging Details:

dip outdoor full color led module Packing: Carton, Wooden box, Flight case

Delivery Detail:

Shipped in 15 days after payment

Promotional Super Thin dip outdoor full color led module Product Description

Specification of dip outdoor full color led module

No.

specs outdoor full color PH12

1 Pixel structure DIP, 346

2 Pixel pitch 12mm 3 Pixel density 6944dots/Sq.

m.

4 Luminance 5000cd/Sq.

m.

5 Module dimension 192mm(W) * 192mm(H)

6 Module resolution 16 pixel(W) *16pixelmm(H)

7 Module weight 1000g

8 Cabinet dimension 1152* 768mm or other

9 Cabinet area 0.79sq.

meter or other

10 Screen weight 40~60kg/m2

11 Optimal visual distance > 12m

12 Visual angel 140 degree (H/V)

13 Max power consumption 900w /Sq.

m.

14 Average power consumption 400w /Sq.

m.

15 Brightness adjustment Adjust according to the enviroment

brightness software (0%-100%adjustable)

16 Drive mode static scan, constant current

17 Input voltage AC 110~220 volts

18 Operation temperature -10° C~ +50° C

19 Operation humidity 10%~90%

20 Input signal DVI, MPG, AVI, WMV, RM etc.

21 Control system DVI card + master control card + receiver card

22 lifetime (50% brightness) >100, 000 hrs

23 Malfunction dot rate 1/10000

24 Cabinet material Epoxy paint coated Cold rolled steel iron/Aluminum 25 Data interconnection UTP Cat 5/Optical Fiber

26 Application: Rental / Permanent installation available
