Tft Lcd Module Analog - China

7'' 480*(RGB)*234 TFT LCD Module:

Product Details:

Place of Origin Guangdong, China (Mainland)

Brand Name Silicon

Model Number Silicon-P-002

Type LCM

LED Backlight Screen Size: 164.9*100*5.5

Payment & Shipping Terms:

FOB Price: Get Latest Price

Minimum Order Quantity: 1 Piece/Pieces

Port: FOB Shenzhen

Packaging Details: 60pcs/Box

Delivery Time: In 15 workdays after payment

Payment Terms: T/T, Western Union

Supply Ability: 100000 Piece/Pieces per Month

Detailed Product Description

1 - 7'' 480*(RGB)*234 TFT LCD Module

2 - Use for display equipment

3 - Input signal: CVBS

4 - Datasheet: yes

1 - Application:

Building interphone, car reversing system

Industrial controlling system, medical equipment

Audiovisual equipment Car display, Portable DVD Player

Household Video door bell, Videophone, Digital Camera

2 - Feature:

Product Name

7'' 480*(RGB)*234 TFT LCD Module

Product Number

Silicon-P-002

Backlight

LED

Resolution

480x(RGB)×234

View Angle ( up/down/left/right )

50/55/60/60

Brightness

> 250Cd/m2

Input Signal

CVBS

System Format

PAL/NTSC(Auto switch)

Supply Voltage

9V-15V

Rated Power

2.5W

Adjust Model

Menu adjust

PCB Structural Dimension(mm)

82(W)×50(H)×7(D)

Screen Size(mm)

164.9(W)×100(H)×5.5(D)

Operating Temperature

-10~60 °C

Relative Humidity

5~95% RH

Storage Temperature

-20~70°C

Packing

60pcs/Box

3.5'' 320x240 TFT LCD Module

Model Number Silicon-P-003

Type TFT

Part name 3.5inch TFT LCD Module

Display 3.5"TFT-LCD (54PIN 4: 3)

Backlight: led

Resolution: 320cx240

Signal input: 2 way CVBS

System format: PAL/NTSC(Auto switch)

Adjust model: Menu adjust

Power Input: DC 9V-18V

Overall Dimension of LCD(mm): 76.9(W)* 63.9(H)*3.15(D)

PCB Structural dimension(mm): 88.0(W)*58(H)*6.8(D)

Packaging Details: bubble bag and standard export carton

4.3'' 480x272 TFT LCD Module

Model Number Silicon-P-004

LED Backlight Screen Size: 105.5*67.2*2.9

4.3'' 480x272 TFT LCD Module

Silicon-P-004

480(RGB)×272

> 350Cd/m2

1.2w

90(W)×48(H)×6.8(D)

105.5(W)×67.2(H)×2.9(D)

-20~70°C

-30~80°C

bubble bag and standard export carton
