China Manufacture High Ranking P8 Smd Led Display Panel - China

Overview

Specifications

Place of Origin:

Shanghai, China (Mainland)

Brand Name:

Leado

Model Number:

outdoor SMD P8

Usage:

Outdoor

Tube Chip Color:

Full Color

Display Function:

Video

Pixels:

8mm

Screen Dimension:

Customized

Name:

p8 smd led display panel

Other name:

China manufacture p8 smd led display panel

Certificate:

CE ROHS FCC

Brightness:

6000cd/sqm

Color:

Full-color

Application:

Live Events Led Display

Warranty:

2years

Module size:

256mm x128mm

Pixel pitch:

8mm

Viewing angle:

H120 V120

Packaging & Delivery

Packaging Details:

p8 smd led display panel Packing: pearl wool + carton + wooden case or flight case

Delivery Detail:

Shipped in 15 days after payment

China manufacture High-ranking p8 smd led display panel Product Description

Specification of p8 smd led display panel

No.

specs outdoor full color PH8

1 Pixel structure SMD, 3535

2 Pixel pitch 8mm 3 Pixel density 15625dots/Sq.

m.

4 Luminance 6000cd/Sq.

m.

5 Module dimension 256mm(W) * 128mm(H)

6 Module resolution 32 pixel(W) *16pixelmm(H)

7 Module weight 270g

8 Cabinet dimension 768 * 768mm or other

9 Cabinet area 0.59 sq.

meter or other

10 Screen weight 40~60kg/m2

11 Optimal visual distance > 8m

12 Visual angel 140 degree (H/V)

13 Max power consumption 1290w /Sq.

m.

14 Average power consumption 645w /Sq.

m.

15 Brightness adjustment Adjust according to the enviroment

brightness software (0%-100%adjustable)

16 Drive mode 1/4 dynamic scan, constant current

17 Input voltage AC 110~240 volts

18 Operation temperature -40° C~ +60° C

19 Operation humidity 10%~90%

20 Input signal DVI, MPG, AVI, WMV, RM etc.

21 Control system DVI card + master control card + receiver card

22 lifetime (50% brightness) >100, 000 hrs

23 Malfunction dot rate 1/10000

24 Cabinet material Epoxy paint coated Cold rolled steel iron/Aluminum 25 Data interconnection UTP Cat 5/Optical Fiber

26 Application: Rental / Permanent installation available
