Mining 3 Ton Trolley Wire Locomotive - China

mining 3 ton trolley wire locomotive Adhesive / total weight (t) : 3 ton Track gauge (mm) : 500.600, 762 or 900 Traction (KN) : 6.1kN/ 5.74kN Max.

Traction (KN) : 7.36kN Speed(km/h) : 10.6km/h/ 7.5km/h Voltage : 250 or 550V Power (KW) : 6.5*2 or 12*1 Dimensions Length(mm) : 2700mm/ 2750mm Width(mm) : 940, 1082 or 1220mm Height(mm) : 1550 Wheelbase (mm) : 816mm/ 850 mm Wheel diameter (mm) : Φ650mm/ Φ520 mm Min Curve radius (m) : 5.7-6 m Controller : Resistance or IGBT Braking method : Mechanical or Hydraulic Brake What should drivers of overhead mining locomotives pay attention to when getting on and off? As an important means of transportation in mines, overhead mining locomotives need to pay attention to safety and operating specifications when drivers get on and off.

The following are some precautions for drivers of overhead mining locomotives when getting on and off.

1 - There should be lighting at the place where the locomotives get on and off: The operating environment of overhead mining locomotives is usually dim, especially underground or in tunnels.

Therefore, sufficient lighting facilities must be installed at the place where the driver gets on and off to ensure that the driver can clearly see the process of getting on and off to avoid accidents.

2 - Ensure that the overhead line is powered off: The power supply of overhead mining locomotives is transmitted through cables installed above the track.

In order to ensure the safety of the driver, the overhead line must be equipped with a section switch or an automatic power-off switch to cut off the power supply.

When people get on and off, the power supply of the overhead line in this section must be cut off to prevent electrical hazards.

3 - Determine the location of getting on and off: Before getting on and off, the driver should ensure that the vehicle is parked in a suitable position.

The parking position of the vehicle should be stable to ensure that the driver can get on and off the vehicle easily and avoid accidents caused by vehicle shaking or instability.

4 - Be familiar with vehicle operation:

The driver should be familiar with the operation and control methods of the vehicle.

Before getting on and off the vehicle, confirm that the vehicle is in a stopped state and the brakes are firmly set.

Before getting on the vehicle, the vehicle dashboard and control equipment should be checked to ensure that the vehicle is in normal working condition.

5 - Pay attention to the surrounding environment:

During the process of getting on and off the vehicle, the driver should pay attention to the surrounding environment, especially whether there are other vehicles or people approaching, to ensure the safety and smoothness of getting on and off.

In summary, when the driver of the overhead wire mining electric locomotive gets on and off the vehicle, he should pay attention to safety first, ensure that the power supply of the vehicle is cut off, choose a suitable place to get on and off the vehicle, use handrails and handles to maintain balance, be familiar with vehicle operation, and pay attention to the surrounding environment.

Only by doing this can the driver's safety and smooth operation of the electric locomotive be guaranteed, and at the same time, work efficiency and work quality can be improved.
