Hsp 9 Wet Mix Shotcrete Machine - China

price: 500.00 Dollar US$

Hsp 9 Wet Mix Shotcrete Machine

Products Photos Catalog Hsp Wet Mix Shotcrete Photos Catalog

CHINA COAL 0001

HSP-9 Wet Mix Shotcrete Machine

Introduction of HSP-9 Wet Mix Shotcrete Machine HSP-series wet shotcrete machine is an advanced and high efficient concrete spraying machine, which has been designed especially for spraying of concrete .

It has the advantages of low dust, low rebound, high-strength concrete, simple operation, convenient for maintaining, prolong operation life etc.

The machine, combined with dosing unite, is suitable for manual spraying or by means of a robotic arm .

It is used for spraying shotcrete in rail and road tunnel, subway engineering, hydro-power engineering, underground engineering, mine gallery and more concrete engineering.

Wet shotcrete is produced by using the mixed concrete first, and then adds accelerator.

Advantages of HSP-9 Wet Mix Shotcrete Machine

1 - Mixing uniformity

2 - Water and cement ratio could be accurate control

3 - good for water and cement hydration

Common use of HSP-9 Wet Mix Shotcrete Machine

1 - Gunite Swimming Pool Construction.

2 - Soil Retention and Tetaining Walls.

3 - Rockscaping.

4 - Refractory Spraying.

5 - Mine Support.

6 - Tunnel Linings.

7 - Concrete Repair.

8 - Artificial Rocks and Caves.

9 - Low-volume Refractory Spraying.

Parameter of HSP-9 Wet Mix Shotcrete Machine item HSP-9

Output 6-9m³/H

Max.

Convey dist Horizontal: 30m

Vertical: 20m

Concrete proportion

1: 4-5C/A

Water cement ratio

≤0.4

Hose inner size Φ51m/64mm

Max.

Aggregate size 15mm

Operating air pressure 0.4-0.6MPa

Air consumption 10-15m³/min

Rotor diameter 480mm(175)

Spring rate level ≤10%

The accelerating liquid adding amount 0.3-0.7%

main Electric motor power Y160m-6-7.5KW

vibration electric motor power 0.37KW

Accelerating metering pump pneumatic

Electric Voltage 380V

Overall dimension(mm)

2000*800*1300

Whole weight 900kg
