High Temperature Pressure Transmitter With 4 20ma - China
price: 150.00 Dollar US$
High tempreture pressure transmitter with 4-20mA can be calibrated to ranges as low as 0 to 1.5 psi (0.1 bar) and as high as 0 to 4000 psi (275.8 bar).
Rosemount 2088 can also be used to measure negative pressure ranges.
The 2088 pressure transmitter measurement capabilities enable reliable use in almost any application.
Compatible with 316LSS, noncorrosive gases & liquids.
Special use in harsh environment conditions.
Measurement Range
-0.1….
0~0.01 - ~100MPa
Proof pressure
≤1.5X rated pressure or 110MPa which ever is less
Pressure type
Gauge, absolute, sealed gauge
Accuracy
±0.25%( Typical) ±0.5%( Max.
)
Long term stability
±0.2%F.
S/year
OperatingTemperatureRa nge
-20℃~80℃
Storage TemperatureRange
-40℃~120℃
Power supply
15~30VDC
Output signal
4~20mA 0~10/20mA 0/1~5VDC
Pressure port
M20×1.5 or customize
material
1Cr18Ni9Ti stainless steel
Diaphragm material
316L
O-ring
Fluororubber
Electrical housing
Cast aluminium alloy(2088housing)
Insulation resistance
100MΩ, 100VDC
Protection
IP65
Company Contact:
- Posted By: Xi'an Yunyi Instrument Co,.ltd
- Phone: 17391772083
- Address: Inland Port Mansion, No.9 Gangwu Road, Xi'an International Trade & Logistics Park, Xi'an City, Shaanxi Province, China
- Email:
- Website: https://yunyiyibiao.en.alibaba.com/
Published date: June 5, 2018
- Business Description: Xi'an Yunyi Instrument Co., Ltd.,
specializing in Piston dead weight tester, pressure calibrator, hand test pump, Pressure gauges / transmitters, level meter , flow meter, temperature and ph instruments with more than 10 years.
