Static Strain Amplifier - China

Static Strain Amplifier Model: CJ2533

Description

CJ2533 adopts intelligent management and high quality components, toggle switch replaced by electronic switch, greatly improved the stability and reliability of the test.

It can be widely used in teaching test field and small engineering testing.

Features ● 4, 8, 16, 24channels (random combine )strain test point and 1 channel force test point; ● 4½ digits LED display test value; ● Synchronized dual-window display; ● Test point and Bridge circuit Indication; ● All parameters can be set and stored; ● To provide fully functional application software; ● Suitable For teaching and engineering testing; ● Small Size, easy to handle.

Model: CJ2533

Input Range 0 - ±19999με(2VDC)

Channal 4, 8, 16, 32, 64

Gage Resistance 60 – 1000 Ω

Resolution 1με

Zero Stability ≤1με/ ℃ ; ≤3με/4h

Sensitivity Stability ≤±0.02％FS/ ℃; ≤±0.1％FS+1με)/2h

Bridge Voltage 2VDC

Bridge Voltage 1, 1/2, 1/4, Common compensation

Accuracy ≤±0.2％FS±2με

Output Analogy BNC；4½ LED Display

Sensitivity coefficient 1.00 - 9, 99

Nonlinearity ≤±0.05%

Balance Range 0 - ±19999με

Scan Speed 6 channels / s

Operating Temperature 0 ℃- +40 ℃

Humidity 95%R.H.

Power Supply AC220V50Hz; DC+9 - +15V AC220V50Hz

Dimensions (mm) 360D ×84H ×3200W

Weight 3.5Kg

Input/Ouput Input: Terminal strip; Output: RS-232C interface
