Rdh 315 160 Butt Fusion Welding Machine - China
price: 1500.00 Dollar US$
RDH－315/160 Hydraulic Butt Welding Machine
Application:
Suitable for butt fusion welding of plastic pipes and fittings made of PE, PP, and PVDF in construction site or workshop.
Features:
1 - consists of basic frame, heating plate, planning tool, and support (for planning tool & heating plate) 2 - Removable PTFE coated heating plate with separate temperature control system.
3 - Electric milling cutter with reversible double cutting edge blades.
4 - Low starting pressure ensures reliable welding quality of small pipes.
5 - Hydraulic unit provides welding machine with compressing power.
6 - It is made of lightweight and high strength material; light weight, simple structure and easy to operate
7 - Separate two-channel timer shows time in soaking and cooling phases.
8 - High-accurate and shockproof pressure meter indicates clearer reading.
\
Technical parameter:
Welding ranges: plastic pipes: 160mm－315mm
(160mm－180mm－200mm －225mm－250mm－280mm 315mm)
Extended to 160mm－315mm
Ranges of application: PE, PP and PVDF
Working voltage: ～220V ±10%, 50Hz.
Total power: 4.95 kW, including: planning tool：1.1 kW, heating plate：3.1 kW, hydraulic unit motor: 0.75kW PTFE coated heating plate, adjustable knob for temperature control, difference in heating plate surface temperature ≤±7°.
Environment temperature: －10° ～ 45°
Electronic count-down timers for heating and cooling time.
Whole machine consists of basic frame, heating plate, planning tool, hydraulic unit and support (for planning tool & heating plate)
Company Contact:
- Phone: 8618921353365
- Address: qianzhou town, wuxi , China
- Email:
- Website: https://www.cnbuttfusion.com
Published date: October 13, 2017
- Business Description: butt fusion welding machine and brand saw cutting machine used in pp pe pvdf hdpe pipe in contruction site or workshop
