Gas Oxidizing Property Chamber - China

Standards

ISO 10156-2010 GB/T 27862-2011 GAT536 NY/T 1860 Product Features

1 - The test device and the control system adopt a split - structure design to ensure the safety of the instrument control unit and experimenters.

2 - PC operation software is provided as a supporting part, reducing the operation difficulty of the instrument.

3 - It supports remote - controlled ignition to ensure the safety of experimenters.

4 - It is equipped with a high - precision pressure sensor, which can accurately measure the explosion pressure and control the concentration of gas partial pressure ratio.

5 - It is equipped with a magnetic stirring device.

6 - It has the function of an electronic micro - processor to control the ignition time.

7 - It has an automatic cleaning function.

8 - It is equipped with an automatic pressure - relief device.

After the test is completed, automatic pressure - relief can be selected to release the pressure in the test tank.

9 - It has multiple explosion - proof functions to ensure the safety of experimenters.

10 - It has a fault - detection function and automatic audible and visual alarm functions.

11 - The test process is fully automated, requiring no manual intervention.

It supports functions such as parameter setting, data storage, and report viewing.

Technical parameters

Operating Environment (5 to 40)°C, <85%RH Test Tank Material Stainless Steel 316L Test Tank Maximum Pressure ≥3000kPa Test Tank Volume ≥0.005m³ Test Tank Fittings Magnetic Stirrer Ignition System Metal Rods Diameter ≥3mm Nickel Chromium Wire Diameter (0.05 to 0.2)mm Ignition Energy (10 to 20)J Explosive Pressure Transducer Detection Range (0 to 5000)kPa Explosive Transducer Pressure Resistance ≥10MPa Explosive Transducer Measurement Accuracy ±0.1%FS Explosive Transducer Response Time ≤1ms Dispensing Gas Transducer Detection Range (0 to 200)kPa Dispensing Gas Transducer Measurement Accuracy ±0.1%FS Temperature Measurement Range (0 to 350)°C
