Solar Simulation Testing Apparatus - China

Recommended related instruments: Solar Simulators The Solar Simulator is a brand-new solar energy simulator that provides a completely new solar energy experience.

It features highly realistic sunlight simulation, accurately mimicking the intensity and angle of sunlight at different times and seasons.

Through the BBA Solar Simulator, users can experience the warmth and comfort of real sunlight.

Applications This BBA device provides an environment close to natural sunlight.

The purpose of the solar simulator is to provide a controllable indoor experimental facility for testing solar photovoltaic modules.

The AAA-grade large-area steady-state solar simulator is primarily used for testing large-area photovoltaic modules, and can perform tests including maximum power testing, temperature coefficient measurement, performance under low irradiance, hot spot durability testing, and photoaging testing.

Standard IEC 61215: Terrestrial Photovoltaic (PV) Modules – Design Qualification and Type Approval IEC 61646: Thin-Film Terrestrial Photovoltaic (PV) Modules – Design Qualification and Type Approval ISO 9060: Solar Energy – Classification of Pyranometers CE Certification (Conformité Européenne) UL1703 Product Advantages BBA-Grade Performance Class B Spectral Matching: Ensures AM1.5G compliance for accurate energy rating.

Grade B Irradiance Uniformity: <5% deviation across 2.0m × 1.0m test area.

Multi-Mode Testing STC/NOCT/Hotspot Simulation: Replicates standard test conditions, nominal operating cell temperature, and thermal runaway scenarios.

1.000 W/m² Tuneability: Adjustable irradiance for low-light performance mapping.

Stability First Class A Transient Stability: <2% flicker during pulsed load testing.

Metal Halide Lamp Longevity: 5.000-hour lifespan with <10% lumen depreciation.

Smart Control AI-Powered Irradiance Correction: Compensates for lamp aging in real-time.

Remote Calibration: Wi-Fi/Ethernet connectivity for ISO 17025 compliance.

Safety First UV Filter: Blocks harmful UVC radiation during operator access.

Emergency Shutoff: Dual redundant safety circuits with GPS-enabled alerts.

Product Features 2.0m × 1.0m Test Area: Accommodates full-size 72-cell modules and small BIPV panels.

6-Axis Robotic Arm: Automates IV curve tracing and EL imaging positions.

10” Sunlight-Readable HMI: Preloaded IEC 61215/61646 test sequences with customizable dwell times.

Self-Cleaning System: Automated lamp housing purging for dust-free operation.

Modular Design: Expandable from 1 kW to 10 kW for pilot-scale production lines.

Accessories Included Testing Kit: 4x PV module test fixtures (adjustable for frameless/framed modules).

10x Type T thermocouples with ceramic insulation.

Software Suite: License key for SolarSim Pro (Windows/Linux).

1-year free access to cloud-based PV simulation tools.

Calibration & Safety: NIST-traceable irradiance meter.

UV safety goggles (Class 1 - 3 pairs).

Maintenance Kit: Spare metal halide lamps and igniters.

Lamp cleaning solution (non-corrosive).

Documentation: Multilingual quick-start guide (printed + digital).

Compliance certificates for IEC/UL/ISO standards.

Technical Parameters

Parameter Specification

Irradiance Range 200–1.200 W/m² (AM1.5G filtered) Spectral Matching Class B (IEC 60904-9) Uniformity Grade B (<5% deviation) Stability Class A (<2% transient flicker) Lamp Type Metal Halide (400 nm–1.100 nm output) Test Area 2.000mm (W) × 1.000mm (D) Power Supply 380V/415V 3-phase, 50/60Hz Dimensions 2.500mm (W) × 1.500mm (D) × 2.200mm (H) Weight 1.800 kg (net) / 2.500 kg (gross)
