Product introduction

This equipment uses xenon arc lamp that can simulate the whole spectrum of sunlight reproduction under different environments the destructive wave, which can provide the corresponding simulation environment and accelerated test for scientific research, product development and quality control.

Aging test of xenon arc lamp under light and heat radiation by exposing material samples.

To evaluate the light and weather resistance of some materials under the action of high temperature light sources.

It is mainly used in automobiles, coatings, rubber, plastics, pigments, adhesives, fabrics and so on.

Detailed specification parameters

Product mix Sigal box vertical Technical parameters of xenon lamp Temperature rang RT℃～+80℃ Light irradiance

Spectral wavelengths: 290nm～800nm Irradiance range: 550W～1200W/㎡

Temperature fluctuation ≤±0.5℃

Temperature uniformity ≤2℃

cooling rate 0.7～1℃/min(Nonlineari ty)

Heating rate 3～5℃/min(Nonlinearity )

Humidity rang 30%～98%R.

H

Humidity fluctuation 3%～4%R.

H Blackboard temperature 63+3℃ Test standards for satisfaction SAEJ-1885 ；SAEJ-1996 ISO 105B-06 ；ISO 105B-02 ；ISO 105B-04 ISO4892-2 ；ISO11341 AATCC16E ；AATCC169(1) JASOM346-93 GMW3414TM Ford Interior ASTM G155-1 ASTM G155-4 Implementation and compliance with standard instructions 1 - ISO 4892-2: 2006 2 - ISO 11507 3 - ASTM G154 Texture of material Material and size of outer box High quality cold rolled steel plate lacquer Deep: 1400 wide: 1450 high: 1950mm Material and size of inner box Imported SUS304 stainless steel deep : 800 wide: 800 high : 800mm Insulation material High quality polyamine foamed 100mm Xenon Lamp House Water cooled xenon lamp 6kw, More than 1200 hours of life, easy to disassemble Features

1 - Presetting various specifications, Custom program capability, meet diverse range of standards, including AATCC, ISO, BS, JIS etc.

2 - Automatic compensating system (PATENT) control the Xenon Lamp Power.

3 - Colorful touch screen, indicate the condition of chamber at real-time, be able to presetting irradiance, temperature (BPT, BST, chamber), humidity, and plot dynamic curve of them.

The operator simply selects the required test module and test standards; English user interface, diagram indicate condition of chamber, easy to use.

4 - PLC control, powerful program and storage property, save the parameters when interrupt of power supply.

5 - Chamber temperature control, irradiation temperature, and heater raise the temperature, air conditioning refrigeration.

6 - Irradiation control, light irradiance sensor monitor, digital setting, automatic compensating system, stepless adjustable.

7 - Sample holder/ rack: 360 degree rotating, can hold samples of different sizes.

8 - Xenon Arc Lamp to simulate the best full spectrum sunlight.
