Diamond Cut Wheel Polishing Repair Machines Ck6187w With Low Cost - China

Quick Details

Condition:

New

Type:

Horizontal

CNC or Not:

CNC

Automatic Grade:

Automatic

Max.

Swing Diameter:

870mm

Place of Origin:

Shandong, China (Mainland)

Brand Name:

HAISHU

Model Number:

CK6187W

Voltage:

380v

Power(W):

11kw

Dimension(L*W*H):

2680X1820X2050(mm)

Weight:

3600KG

Certification:

ISO9001: 2008, CE

After-sales Service Provided:

Engineers available to service machinery overseas

Name:

Diamond Cut Wheel Polishing Repair Machines CK6187W

Machine Type:

Lathe Machine CNC

Color:

White

Function:

Rim Surface Repair

Product type:

Alloy Wheel Refurbishment

Warranty:

12 Months

Precision:

High Precision Machine

Spindle bore:

82mm

Spindle speed:

150-2500rpm

Control system:

SYNTEC or touch screen

Diamond Cut Wheel Polishing Repair Machines CK6187W provides you best CNC machine solutions for alloy automobile wheel machining, super finishing and maintenance, it has the characteristics of high quality, high precision and high efficiency.

The CNC wheel machine, wheel repair machine and brake drum lathe are widely used in automobile wheel factories and some repair shops.

Our partners are those famous brand from European countries, United state, South Korea, Russia and Asia etc.

Diamond Cut Wheel Polishing Repair Machines CK6187W Technical parameters Project name

Unit

Technical paramaters

Max.

turning diameter over the bed

Inch

34”(φ870mm)

Machining diameter of the wheel

Inch 30

Max.

machining length of the workpiece mm

750

cnc system SYNTEC or Touch screen

detection mode touch probe or laser

Machning accuracy IT6-IT7

Surface roughness

um

Ra0.8~1.6

Main transmission form Independent spindle; frequency conversion stepless

Range of spindle speed

rpm

150~2000

Main motor power

kw

11

Fast-moving feed

mm/min

X - axis: 5000 Z - axis: 8000

Repeat positioning accuracy

mm

X - axis: 0.01 Z - axis: 0.015

Standard accessories 4 station electric tool

Repeat positioning accuracy(mm)

mm

0.008

Section of turning tool(mm)

mm

25×25

The size of the machine

(L×W×H)

mm 2680×1820×2050

Net weight of the machine(kg)

3600 Diamond Cut Wheel Polishing Repair Machines CK6187W Main features

1 - Achieve the wheel surface profile measurement and data collection and Program Optimization, 2 - Automatic precision repair and machining in accordance with the curve of the wheel surface

3 - Spindle frequency stepless speed;

4 - X / Z axis servo drive;

5 - Manual jaw self-centering chuck;

6 - Machine guard full protection;

7 - Automatic oil lubrication.

Diamond Cut Wheel Polishing Repair Machines CK6187W Uses

1 - The machine tool suitable for High-precision turning and repair processing for surface of car wheel.

2 - The machine tool has also the function of the general CNC lathes .
