Hz 200yy Hydraulic Core Drilling Rig - China

price: 180.00 Dollar US$

1.Applications of HZ-200YY hydraulic core drilling rig
HZ-200YY hydraulic core drilling rig is mainly used for geological general investigation and exploration, road and tall building foundation exploration, holes in concrete structure, river levees, civil water wells and ground temperature central air-conditioner.
2. Features of HZ-200YY hydraulic core drilling rig
·the highest speed can reach 1045r/min with 5 gears, which improves drilling efficiency
·adopted 53*59 drilling rod, which has high rigidity and strong delivery torque.
·equipped with taper clutch, made the machine easy to operate and free of maintenance.
·using large module planetary gear and adding supporting frame, which highly increased hoisting and braking ability of the winch.
·vertical spindle are fixed by four groups of bearings to ensure that the core drilling rig is rigid enough for gravel layer and other complex geological conditions.
3. Technical parameters of HZ-200YY hydraulic core drilling rig
Max open hole diameter 300mm
End hole diameter 75mm
Drill rod diameter 60mm
Drilling angle 90
Drill weight (without power) 975kg


Company Contact:


  • Phone: +8619806265526

  • Address: Wu taizha road, guanhe street, jining hi-tech zone, shandong province, Jining, Shandong, China

  • Email: Email


Published date: June 26, 2019 -

  • Business Description: Mechanical equipment and accessories, flood control equipment, track equipment, electric tools, hydraulic equipment, pneumatic tools, explosion-proof electrical appliances, instruments, pumps
