Full Auto Pipe Cutting Machine - China

Full Auto Pipe Cutting Machine

Pipe Cutting Machine Model: MC-400NC

Max.

Cutting Capacity: ￠120mm

Cutting Degree: 90°

Automatic Feeding Way: Cylinder

Blade Rotating Motor Power: 4.5/5.5 KW

Water Pump Motor Power: 90W

Hydraulic Pump Motor Power: 4KW

Feeding Length: 6-700mm/time

Blade Rotating Speed: 120/60 Giri/min

Hydraulic Pressure: 45-70kgf

Available Saw Blade Size: ￠250/275/300/315/350/40 0mm

Machine Dimension: 2800*1100*2000

Machine Weight: 1680kgs

SLS automatic pipe cutting machine with function of hydraulic clamp, hydraulic feeding and hydraulic cutting.

Automatic feeding ensure high cutting accuracy and increase productivity.

Good mechanical system ensures high cutting quality without burrs on tube internal and external.

Water cooling and lubricate system prolongs the life of machine and saw blade.

Each cold saw is covered by a one year parts warranty plus lifetime technical support by SLS.

We keep many cold saw models in stock for quick shipments.

STANDARD

Automatic Hydraulic Feeding, Automatic Hydraulic Clamping and Automatic Hydraulic Cutting.

Rigid cast iron saw bases and electro-welded steel frames maintain accuracy and minimize vibrations, even at full capacity.

Material of cold saw machine is available: Steel&Stain less Steel.

Cutting Shape Available: Round, Square, Rectangle and other profiles.

Available for several pieces cutting together for small pipe size.

2 sides and 2 way clamping system: High precision cutting, reduce vibration and soundless while cutting.

Clamping, saw blade advancing, backward, clamp releasing are all hydraulic driven.

Good mechanical parts ensure machine runs in high stability.



CE, ISO9001 Certification.

OPTIONAL

Tube Material Supporter for long tube

Special clamp jaw for special pipe size
