Semi Automatic Vertical Tube Bender - China

Semi-Automatic Vertical Tube Bender

Vertical Tube Bender

Model: SB-38NC(Vertical)

Max.

Bending Capacity: ￠38.1 (1.5”)×2mm

Bending Degree: 0-190°

Bending Radius: 20-200mm (for machine)

Min Bending Radius: R≥1.5D (for pipe)

Mandrel Length: 2000mm(can be customized)

Max.

Bending Speed: 90°/s

Bending Accuracy: ±0.1°

Motor Power: 4 Kw

SLS Semi-automatic Vertical Tube Bender has an NC control unit to allow the operator to program the bend degree (C axis)-the standard memory can store up to 16 programs each with 16 sequential bends.

Tube bending machine allows the operator to select from the memory to bend sequence they require and load the tube and start bending.

The rotating and feeding (B&Y axis) are controlled manually.

Other movements as die working, mandrel working are controlled by hydraulic.

Pipe bender combines easy-to-use operation with high bending accuracy and cost effectiveness.

Semi-automatic Vertical Pipe bending machine is the practical semi-automatic solution for small to medium productions.

STANDARD

Bending Axis-by Hydraulic, Feeding Axis-by Manual, Rotating Axis-by Manual.

Human Interface offers easy access to auto and manual operating modes.

Fully hydraulic movement on clamp die, pressure die and mandrel.

Available pipe material: steel, stainless, aluminum, titanium and brass.

Available pipe shape: Round, Square, Rectangle, Oval, Solid Bar, other profiles.

Equipped with encoder ensures the accuracy and stability of bending.

Equipped with adjustable speed valve on pressure die ensures the synchronization of bending.

Water cooling system ensures the equipment long-time work stably under the high temperature.

CE&ISO 9001: 2000.

OPTIONAL

Anti-clockwise bending

Extra mandrel length

PLC controlling

Feeding length positioner

Mandrel lubrication function

Air cooling device

Cooling Conditioner

Safety mat

TOOL:

STANDARD MATERIAL: 45# STEEL

OPTIONAL MATERIAL:

Ampco Bronze- Mandrel&Wiper die for Stainless Steel Pipe

Nylon- Bending die, Clampe die&Pressure die for Aluminum Pipe

Cr 12-For other pipe material

ACCESSORIES:

TOOL, TOOL BOX, MANUAL OPERATION, INSTALLATION DVD, SPARE PARTS
