Bone Plates Static Four Point Bending Tester - China

Standard

YY/T 0342-2022: Chinese standard specifying methods for determining bending strength and equivalent bending stiffness of straight and pre-angled metallic bone plates.

ASTM F382: International standard covering mechanical testing, dimensional requirements, and reporting protocols for metallic bone plates.

Product Advantages

High-Precision Force Application: Electromagnetic load frame with ±0.1% accuracy, ensuring compliance with YY/T 0342’s force resolution requirements.

Adjustable test speed (0.001–500 mm/min) for static and quasi-static loading.

Customizable Fixturing: Modular four-point bending clamps with interchangeable roller diameters (6–13mm) and contour-matching designs to accommodate straight, angled, and pre-curved bone plates.

Anti-slip mechanisms and specimen alignment guides for consistent results.

Advanced Data Acquisition: Real-time monitoring of force, displacement, and bending stiffness with 5000Hz sampling rate.

Automatic calculation of key parameters: bending strength (MPa), equivalent stiffness (N/mm), and yield points.

User-Centric Design: Intuitive software with preloaded SOPs for YY/T 0342 and ASTM F382 compliance.

Multi-language interface (English/Chinese/Spanish) and exportable reports (PDF/Excel/CSV).

Durability & Safety: Corrosion-resistant steel frame and overload protection system for long-term reliability.

Low-noise operation (<65 dB) suitable for laboratory environments.

Product Features

Load Capacity: 10 kN (axial) / 500 Nm (torsional).

Force Resolution: 0.01 N (axial) / 0.001 Nm (torsional).

Displacement Accuracy: ±0.5 μm.

Testing Modes: Bending stiffness (ASTM F382).

Bending strength (YY/T 0342).

Load-deflection curve analysis.

Software Suite: Customizable test profiles with automated pass/fail criteria.

21 CFR Part 11 compliance for audit trails and electronic signatures.

Calibration: NIST-traceable certification included, with annual recalibration available.

Accessories (Included/Optional)

Standard Kit: Four-point bending clamps (6mm, 9.5mm, 13mm rollers).

Calibration weights and digital torque wrench.

Test control software with preloaded SOPs.

Optional Upgrades: Axial-torsional load frame (for combined loading tests).

Environmental chamber (for thermal cycling tests).

Custom fixturing for pediatric/specialized bone plates.

Remote diagnostics and preventive maintenance package.

Technical Parameters

Parameter Specification

Force Range 10 N–10 kN (axial)

Torque Range 0.1–500 Nm (torsional)

Crosshead Speed 0.001–500 mm/min

Temperature Range Ambient (optional: -20°C to +150°C with chamber)

Power Supply 220V/110V, 50/60Hz

Dimensions (W×D×H) 600×500×1.600 mm

Weight 280 kg

Compliance CE, ISO 13485 - YY/T 0342 - ASTM F382
