Medical Injection Needle Rigidity Meter - China

Standard

GB 18457-2001 This standard mandates precise control over needle wall thickness (normal, thin, ultra-thin) and rigidity performance, directly impacting patient comfort by minimizing pain during injections.

Product Features

Advanced Testing Principle: Measures needle deflection by applying a vertical force at the center of a defined span, simulating real-world stress conditions.

Comprehensive Kit: Includes a main testing unit, calibration weights, specialized jigs, and a printer for instant data documentation.

Adjustable Parameters: Customizable span distance (0–55mm) and loading speed (1mm/min ±0.1mm/min) to accommodate diverse needle types.

Safety & Compliance: Ensures needles meet rigidity thresholds to prevent bending during use, enhancing patient safety.

Ergonomic Design: Compact dimensions (460mm×340mm×400mm) optimize laboratory workspace efficiency.

Technical Parameters

Parameter Specification

Deflection Measurement 0–5mm, Accuracy ±0.01mm

Load Capacity 5.5–60N, Accuracy ±0.1N

Span Adjustment 0–55mm, Accuracy ±0.5mm

Needle Compatibility 0.3mm–3.4mm (Normal/Thin/Ultra-Thin Wall)

Loading Speed 1mm/min ±0.1mm/min

Dimensions 460mm × 340mm × 400mm

Weight 25kg

Power Supply AC 220V/50Hz or Customized

Warranty 1 Year + Lifetime Standard Upgrades
