Z5040 Drill Press In Machinery Hydraulic Drilling Machine Pdf - China

The main performance characteristics： 1 .

Novel design and beautiful appearance, the structure of the chips, a wide range of variable speed.

2 .

Unique working table, electric and manual lifting mechanism, easy to operate.

3 - the table can rotate 180 degrees or 45 degrees, and it can be used for a wide range of application.

4 - The is provided with a cooling device and tapping device.

5 .

Electrical system to implement the IEC electrical standards, with a short circuit and overload protection function, the main motor power large.

6 .

Unique protective devices, safe and reliable.

Application：

This machine is designed for drilling, counter boring, reaming, tapping, spot facing, etc.

The max drilling diameter is 50mm on small or middle sized workpieces.

It is widely used in machine works and repair shops for single piece or small lot production, having the features of abundant horse power and high rigidity when compared with all the others of its kind at home and abroad.

Standard accessories:

Work lamp, coolant system, fender device, tool box and tools Optional accessories:

Lifting table by motor

Product main technical Specifications:

Specifications Units Z5050

Max.

Drilling diameter mm 50

Spindle taper MT4

Distance spindle axis to column generating line mm 375

Spindle travel mm 230

Spindle speeds range r/min 54-2090

Max.

spindle nose to table mm 800

Max.

spindle nose to base mm 1300

Dimension of worktable surface mm 600x600

Dimension of base table mm 860x600

Width of T slot 18

Spindle feeds mm/r 0.05, 0.1, 0.15, 0.2, 0.25, 0.3

Spindle motor power K w 3.0/2.4

Coolant motor w 40

G.

W/N.

W kg 920/820

Overall dimension cm 61x102x245

Packing dimension cm 258x75x114
